TECHNICAL ACTIVITY

5.1 The satellite communication

system The consolidation of Hisdesat as one of the

principal worldwide suppliers of secure communication services

by satellite, on the military K and Ka bands, for governmental
applications, is now a reality with its range of satellite

communication systems.

The aforementioned system has as its objective to
provide communication services for applications of a
governmental nature, both civilian and military. It con-
sists of the following systems:

 SpainSat. Located at 30º West, it provides
coverage which includes practically the
entirety of the American continent, Africa
and Europe through to the Middle East.

 Xtar-Eur: Located at 29º East, it provides
coverage from Brazil through to Indonesia,
including Europe, Africa, the Middle East
and a large part of Asia. antennae have been configured in such a way that
they provide a combination of beams, both fixed and
The platforms of the two satellites of the Hisdesat adaptable, in order to maximize the flexibility of the
system, SpainSat and Xtar-Eur, are based on the system. The adjustable beams have no restrictions in
LS-1300 Space Systems/Loral model, with 3-axis terms of where they point within the area of coverage
stabilization, the effectiveness and reliability of which of each satellite and at any time may be trained upon
has been demonstrated on numerous previous mis- a specific area. On the other hand, various transpon-
sions. Overall, the satellites built by SS/L have accu- ders can be used with the same beam.
mulated over 1.100 years of service.
Each satellite is capable of providing 1.000 MHz of
Both satellites have been designed to provide service dual-polarized broadband, both to the right and left,
during a 15 year operational life and the onboard thereby optimizing the use of the spectrum available.
